Spatial Light Modulator

Santec 's LCOS (Liquid Crystal on Silicon) Spatial Light Modulator (SLM) is an optical device that precisely controls the phase, amplitude, and polarization of light. Its key features include WUXGA (1920 x 1200) high resolution, 10-bit (1024 levels) phase resolution, and phase stability of less than 0.002π, providing excellent wavefront control performance.

What is a Spatial Light Modulator?

Spatial light modulators are optical devices that electrically control the spatial distribution of light amplitude, phase, or polarization. They are widely used in cutting-edge applications such as holography, AR displays, laser beam shaping, optical communications, and quantum computing, and play an important role in modern optical systems.

Explore use cases of Santec Spatial Light Modulators ❯

SLM-310

High-Power Spatial Light Modulator (1 kW Power Handling)

High-output model for laser processing, 1kW-rated with near infrared wavelength.
Wavelength: 1020–1100 nm
Resolution: WUXGA (1920×1200)

제품 상세보기 ❯

SLM-210

High-Speed Spatial Light Modulator

Enables holographic reproduction with smooth and rapid real-time response. Three types (A/B/C) are available based on your specific application.
Wavelength: A: 400-700 nm, B: 750-1100 nm, C: 450-1600 nm
Response speed: A: Tr:6 / Tf:18 ms　B: Tr:17 / Tf:53 ms　C: Tr:48 / Tf:200 ms

제품 상세보기 ❯

SLM-300

High-Power Spatial Light Modulator (200 W Power Handling)

Suitable for a wide range of high-output applications including metal processing, bio-optical research, etc. Equipped with water-cooling system.
Wavelength: 532, 800, 1064 nm
Resolution: WUXGA (1920×1200 )

제품 상세보기 ❯

SLM-250

UV Hardened Spatial Light Modulator

A high-performance model with optimized liquid crystal and optical thin film structure as well as excellent UV resistance.
Wavelength: 365-550 nm
Resolution: WUXGA (1920 × 1200)

제품 상세보기 ❯

SLM-200

Standard Spatial Light Modulator

Ideal for a wide range of applications requiring precise spatial light modulation. Achieves highly precise light control.
Wavelength: 400-1600 nm*
*Please refer to the AR coating options in Datasheets for details.
Resolution: WUXGA (1920×1200)

제품 상세보기 ❯

SLM-30

Embedded Module of high power spatial light modulator

Designed for integration in industrial equipment. Inherits the functions of the SLM-300, while achieving a compact size and low cost.
Wavelength 532, 800, 1064 nm
High-power durability up to CW 200 Watts
WUXGA (1920 x 1200) resolution

제품 상세보기 ❯

SLM-20

Embedded Module of standard spatial light modulator

Designed for integration in industrial equipment. Inherits the functions of the SLM-200, while achieving a compact size and low cost.
Wavelength range 400-1600 nm
WUXGA (1920 x 1200) resolution

제품 상세보기 ❯
